As a highly versatile touring bike the Bridge Club hits the sweet spot that separates on- and off-road excursions. The simplistic design makes it fully adept to handle a full rack and pannier setup frame bags or any combination of the two. It doesn’t feel sluggish on paved shortcuts but can also hold its own on dirt detours. If you’re feeling a little zesty on your next road tour you won’t be ill-prepared for reroutes through the woods. The Bridge Club is designed to handle it all.
100% Surly Chromoly frame main triangle is double-butted; 1-1/8″ threadless Chromoly fork
Rack fender and four sets of three-pack mounts
Disc brake-specific single-position vertical rear dropout makes it less intimidating than other bikes in the category
Clearance for 700 x 47mm (with or without fenders) or 27.5 x 2.8″ tires (27.5 x 2.6″ with fenders)
| Rear Axle |
QR x 141mm |
| TT (Effective) |
630 |
| Brake Type |
Disc |
| Fork Type |
Rigid |
| Fork Material |
Steel |
| Frame Material |
Steel |
| Frame Type |
Rigid |
| Front Axle |
QR x 100mm |
| Color |
Lingering Cranberry |
| Mfg Size |
X-Large |
| Platform |
Bridge Club |
| Wheel Size |
27.5″ |
| Defined Color |
Red |
Build Kit
Complete Bike Weight: 29 lb 5 oz (Medium) — Specifications subject to change without notice.
Frameset
| Frame |
Surly Bridge Club – 100% Surly Chromoly steel, Natch tubing, double-butted main triangle, TIG welded, E.D. coated |
| Color |
Lingering Cranberry |
| Fork |
Surly Cocktail Fork – 100% Surly Chromoly steel, Natch tubing, double-butted tapered fork blades, TIG welded, E.D. coated |
Components
| Headset |
FSA Orbit MX |
| Seatpost Clamp |
Surly Stainless 30.0 |
| Seatpost |
Promax SP-2016, 27.2 x 350mm, 12mm offset |
| Stem |
Promax DA-296, 31.8mm |
| Grips/Bar Tape |
Velo Black |
| Saddle |
WTB Volt Medium |
| Handlebar |
Salsa Bend |
Drivetrain & Brakes
| Front Derailleur |
N/A |
| Rear Derailleur |
Shimano CUES U6000 GS |
| Cassette |
Shimano CUES LG400, 11-50t, 11spd |
| Chain |
KMC eGlide EPT |
| Crankset |
Shimano CUES U6000, 32T |
| Shifter |
Shimano CUES U6000 |
| Brake Levers |
Tektro HD-M275/276 |
| Brake Calipers |
Tektro HD-M275/276, 2-piston |
| Bottom Bracket |
Shimano BB-MT501 |
| Rotors |
Tektro 160/160, 6-bolt |
Wheels & Tires
| Front Tire |
Teravail Ehline 27.5 x 2.5″, Durable, 60tpi, Tubeless Ready, WTB TCS Sealant Included |
| Rear Tire |
Teravail Ehline 27.5 x 2.5″, Durable, 60tpi, Tubeless Ready, WTB TCS Sealant Included |
| Front Hub |
Novatec QR x 100mm, 6-bolt, 32h |
| Rear Hub |
Novatec QR x 141mm, 6-bolt, 32h |
| Spokes |
14G Black |
| Rim |
WTB ST i30 27.5″, TCS 2.0, 32h |
