A new 36mm chassis to deliver exceptional control
The SL Super-Light Air system offers small bump sensitivity, mid-stroke supprt, and bottom out resistance at a lower weight than the previous OTT
The D1 damper features updated high-flow compression and rebound porting to allow a linear suspension dynamic. This initial damping support without any high-speed harshness paired with a 22% increased volume in the Compression Bladder System results in increased small bump sensitivity and damping consistency
High flow linear rebound update increases response without a loss of control or damping
A purpose-built crown increases drop for extra down tube clearance and featuresstrategically varied wall-thickness for improved stiffness and strength
| model |
Diamond 36 D1 SL |
| wheel size |
29″ |
| steerer (stem/race) |
tapered (28.6/40mm) |
| offset |
44mm |
| travel |
160mm |
| spring type |
air |
| brake mount |
disc only (PM-180) |
| dropout |
15x110mm Boost |
| weight |
2200g |
| color |
grey |
